Us Ningbo Kaxite Sealing Materials Co., Ltd is the manufacturer and exporter of Small Size Winding Machine for Spiral Wound Gasket. We have Full Range Spiral wound gasket machine, Camprofile Gasket Manufacturing Machine, Double Jacketed Gasket Machine and Graphite Gasket Machine Machine. With our experience and knowledge to offer customer with innovative, efficient and reliable solutions for gasket making
Medium Size Winder machine for making spiral wound gasket is used for making spiral wound gasket Diameter size from φ150-φ1500 mm, the machine can produce spiral wound gasket with inner ring or without inner ring. Drive system in maintenance-free mode. It can produce different size spiral wound gasket when Speed adopts frequency conversion speed regulation
Automatic Winding Machine For Making Spiral Wound Gasket is used for making spiral wound gasket Diameter size from φ15-φ500 mm, the Automatic Winding Machine For Making Spiral Wound Gasket is designed to improve productivity, insure the repeatability of quality and operate simply. When operating, just need to feed metal strip and filler material to produce spiral wound gasket with inner ring or without inner ring from 15 mm to 500 mm gasket size. Product quantity, revolutions, gasket size and welding parameter like welding point quantity and position etc. is set simply by touch PLC screen interface.
Full Automatic Spiral Wound Gasket Winding Machine is used for making spiral wound gasket Diameter size from φ19-φ80 mm, the Full Automatic Spiral Wound Gasket Winding Machine is designed fully automatic, easy to operate to make spiral wound gasket. All process for making spiral wound gasket is controlled by touch screen including the Steel Tape feeding and cutting, graphite filler tape feeding and cutting, accurate measurement of dimensions (cover average), spot welding points and solder joint distance, position positioning, etc. Provide a reliable guarantee for the quality of the gasket product.
Large Size Horizontal Spiral wound gasket Winding Machine is used for making spiral wound gasket Diameter size from φ250-φ2500 mm, welding point quantity and position is set simply in advance. Large Size Horizontal Spiral wound gasket Winding Machine is very simple operation to make gaskets, The machine operation speed adopts variable frequency stepless speed change, which can adapt to the speed requirement for different specifications.
