Small Size Winding Machine for Spiral Wound Gasket

Small Size Winding Machine for Spiral Wound Gasket

Us Ningbo Kaxite Sealing Materials Co., Ltd is the manufacturer and exporter of Small Size Winding Machine for Spiral Wound Gasket. We have Full Range Spiral wound gasket machine, Camprofile Gasket Manufacturing Machine, Double Jacketed Gasket Machine and Graphite Gasket Machine Machine. With our experience and knowledge to offer customer with innovative, efficient and reliable solutions for gasket making

Model:KXT-300

Send Inquiry

Product Description

Small Size Winding Machine for Spiral Wound Gasket



Style KXT-300 Small Size Winding Machine for Spiral Wound Gasket

Us Ningbo Kaxite Sealing Materials Co., Ltd is the manufacturer and exporter of Gasket Machine. We have Full Range Spiral wound gasket machine, Camprofile Gasket Manufacturing Machine, Double Jacketed Gasket Machine and Graphite Gasket Machine Machine.

With our experience and knowledge to offer customer with innovative, efficient and reliable solutions for gasket making.


Small Size Winding Machine for Spiral Wound Gasket is used for making spiral wound gasket Diameter size from φ15-φ300 mm, metal spiral wound gasket processing. The roller device adopts pneumatic pressure, large adjustment range, Very simple operation to make gaskets, The machine operation speed adopts variable frequency stepless speed change, which can adapt to the speed requirement for different specifications.


What Gasket Size the Machine Can Make:

Thickness: 4.5 mm (also suitable for 2.5 mm, 3.2 mm, 6.4 mm and 7.2 mm after changing roller parts, V shape winding or W shape winding)


Steel tape: Standard (V or W shape) or custom shaped steel profile


Description Value Unit
Operating mode
Gasket nominal thickness 3.2 or 4.5 mm
Minimum inner diameter with inner ring 15 mm
Maximum outer diameter of the gasket 300 mm
Tolerance of gasket outer diameter +/- 0.3 mm
Total Power  2.2 KW
Power Supply 380/220 as request, 3 phases V
Approx. machine size 128 x 88 x 120  cm
Total weight of machine Approx. 240 Kg
